Level7BMX

Position One Expert

Position One Expert

Regular price $459.99
Regular price Sale price $459.99
Sale Sold out
Shipping calculated at checkout.
Color

POSITION ONE

POSITION ONE Bikes offers you one of the best BMX Racing Bikes for your first ride & race on track & help get you on the way to becoming a future BMX Champion.  We offer 5 sizes in the Position One BMX Racing line. We start by using the winning race proven geometry from our championship winning brand, Chase BMX, to create a truly certified BMX racing bike. We then load the POSITION ONE bikes w/ real BMX racing parts, giving you not only a real race bike, but the best value for your money in a entry-level race bike, from a company that actually races. All of our POSITION ONE racing bikes feature a 6061-T6 alloy frame w/ integrated head tubes, race perfect geometry, 100% chromoly bars & forks, sealed hubs, double walled rims, & raced tuned parts from great companies like KMC, VEE RUBBER, & ARISUN.

  • Frame Expert 19.75" Top Tube
  • Fork Full Cr-mo Fork
  • Head Set Integrated Sealed Bearing
  • Chain Ring 5 Bolts 42 Tooth
  • Crank Alloy 165mm
  • Chain KMC Z33
  • Rims Double Wall 28H 1-3/8"
  • Tires Arisun XLR8 1-3/8"
  • Seat & Seat Post Mini Combo 25.4mm

RECOMMENDED SIZE: 4' 4" - 4' 9,5" / 1m32 - 1m46
WEIGHT: 8.6 KG / 18.96lbs w/out pedals

GEOMETRIES:

cadre

FRAME SIZE TT CS min LR AF SA HT SPL BBH WHEELS
Micro 16.15 - 410.21 mm 10.85" - 275.6 mm 1.8" - 46 mm 71° 69° 4" - 100 mm 8" - 203.5 mm 9.10" - 231.14 mm 18×1"
Mini 17.25" - 438.15 mm 12.5" - 317.5 mm 1.8" - 46 mm 72° 70° 4" - 100 mm 8.65" - 219.71 mm 10.6" - 269.24 mm 20×1-1/8"
Junior 19" - 482.6 mm 13" - 330.2 mm 1.8" - 46 mm 73° 72° 4" - 100 mm 8.75" - 222.25 mm 10.6" - 269.24 mm 20×1-1/8"
Expert 19.5" - 495.3 mm 13.25" - 336.55mm 1.8" - 46 mm 74° 72° 4" - 100 mm 8.75" - 222.25 mm 11" - 279.4 mm 20×1-3/8"
Pro 20.5" - 520.7 mm 14.25" - 361.95 mm 1.8" - 46 mm 74° 72° 4.33" - 110 mm 9.25" - 234.95 mm 11" - 279.4 mm 20×1.75"

PRODUCT DETAILS

  • FRAME Expert 19.75" Top Tube 6061 T6 Alloy, Integrated Head Tube, 1-1/8", Water Decals
  • FORK Full Cr-Mo, 1-1/8" Steer Tube
  • HANDLEBARS 5.75" Rise, 24.5" Wide, 8° Back Sweep & 2° Up Sweep
  • GRIPS 130mm Soft Single Ply Without Flange
  • STEM Top Load 50mm 6061 T6 Alloy
  • HEADSET Integrated Sealed Bearing
  • CRANKS 3 Piece Crank 165mm Alloy Arm, Cr-Mo Chain Ring Bolts / Nuts
  • BOTTOM BRACKET 118mm Sealed Bearing Square BB
  • CHAINRING 42 Tooth 5 Bolt 110mm 1/2"X3/32" 3mm Steel Ring
  • CHAIN KMC Z33 1/2"X3/32"
  • PEDALS Platform PP 9/16"
  • RATIO GEAR 42x16
  • SADDLE Mini Combo
  • SEAT POST Mini Combo 25.4mm
  • SEAT POST CLAMP Alloy 1 Bolt
  • FRONT RIM Double Wall 28H 20x1-3/8" Presta Valve
  • REAR RIM Double Wall 28H 20x1-3/8" Presta Valve
  • FRONT HUB 28H, Double Contact Seals Bearing, 3/8" Axle/Nuts
  • REAR HUB 28H, Double Contact Seals Bearing, 3/8" Axle/Nuts, Freewheel
  • COG 16 Tooth
  • SPOKES 14 Gauge
  • NIPPLES Brass Nipples
  • FRONT TIRE Arisun XLR8 20x1-3/8"
  • REAR TIRE Arisun XLR8 20x1-3/8"
  • TUBES 20x1-3/8" Schrader Valve
  • BRAKE LEVER Alloy Junior/Expert
  • REAR BRAKE Alloy 95mm
  • WEIGHT 8.6 KG / 18.96 LB Without Pedals
  • FRAME SIZE Expert
  • RIDER SIZE 4'4" - 4'9.5"
