Odyssey Clutch Pro Freecoaster Hub

Odyssey Clutch Pro Freecoaster Hub

Regular price $199.90
Regular price Sale price $199.90
Sale Sold out
Shipping calculated at checkout.
Style

The evolution of our proven Clutch freecoaster hub continues. The Clutch Pro comes built w/ an all-new bearing equipped drag mechanism for smooth backpedaling & fast crankflips.

Based on direct feedback from Odyssey team riders, the Clutch Pro also features all-new plastic guard designs. The drive side guard provides maximum coverage to the chain & spokes while eliminating the need to spread the frame’s dropouts during installation, which can be detrimental to the frame's integrity. On the hub’s non-drive side, the guard makes use of a new shape for improved spoke coverage & durability.

To adjust the hub’s slack, a new tool-free external button engages w/ an internally threaded adjuster, then simply rotating the wheel forward or backward increases or decreases the slack as needed. The Clutch Pro also comes w/ a grease port so the hub can be lubricated w/out disassembly.

KEY FEATURES:

  • Ultra-smooth crankflip friendly drag mechanism
  • Unique drive side plastic guard design eliminates dropout spreading
  • Redesigned non-drive side plastic guard
  • Tool-free slack adjustment
  • Grease port simplifies lubrication
  • Proven, ultra-durable bearing arrangement
  • US Patent 9,469,157

SPECS:

Driver: 9T, RHD or LHD
Axle: 4140 chromoly w/ in-bound 14mm bolts
Spoke Configuration: 36-Hole
Color: Black
Weight: TBA

WHEEL BUILDING INFO:

Drive Side Effective Flange Diameter: 56mm
Non-Drive Side Effective Flange Diameter: 49mm
Drive Side Flange to Center: 28mm
Non-Drive Side Flange to Center: 29mm

BEARINGS:

Hub Shell Non-Drive: 6003 Sealed
Hub Shell Drive Side: 7905A Sealed
Driver: K 20x24x13 Precision Caged Needle Roller
