2026 Fit Misfit 16"

With young riders pushing the level of riding, smaller bikes need to keep up. The MISFIT 16” is the smallest bike in our line to feature a fully sealed Integrated Headset. Utilizing a CNC machined headtube, also drilled for thread-on Gyro tabs, the headset rests inside the head-tube rather than in press-in cups to avoid broken cups or the lower cup shifting when a fork is bent causing a tight spot in your headset. Also drawing influence from its aftermarket counterpart we’ve lightened up the frame & fork for ’26 creating a bike as limitless as riders imaginations.

MISFIT 16″ Specs:

TT SIZE: 16.25”

FRAME: Cro-Mo Top & Down Tubes

GEOMETRY: 16

HEADSET: Integrated w/Gyro Holes Integrated

BB: Mid Sealed

BARS: 2-Piece 7” x 24”

FORK: New 31mm Offset Cro-Mo Steerer

STEM: Mini Top Load

SEAT: 25.4mm Flatter/ More Padded Integrated Combo

CRANKS: Tubular Cro-Mo 127mm

SPROCKET: Fit Bite 24T

PEDALS: Nylon Platform 9/16”

FRONT WHEEL: Wider 20H Single Wall w/Unsealed Hub

REAR WHEEL: Wider 20H Single Wall w/Sealed 9T Cassette

TIRES: FIT OEM 2.25”

BRAKES: U-Brake w/Low Tension Springs, Short Reach Lever, Linear Cable

MISC: 17mm Rear Axle Nuts
