The ALVX AF is the latest incarnation of the ALVX frame, this new version features a super tech invest cast chainstay yoke which gives even more tire clearance as well as stiffening up the rear triangle. Your wheel can be slammed at an extremely short 12.5" CS length w/ no worries of your tire rubbing!!
KEY FEATURES:
- Alex Donnachie signature
- Super short rear end slammable to 12.5"
SPECS:
| Toptube lengths | 20.3" / 20.6" / 20.8" / 21" |
| Headtube angle | 75.5° |
| Headtube length | 117mm |
| Seattube angle | 71° |
| Rear end length | 12.5-13" |
| BB Height | 11.7" |
| Standover height | 8.7" |
| Weight | 5lbs |
| Brake mounts | none - brakeless |
| Tubing | Sanko Japanese seamless 4130 CrMo / triple butted |
| Headtube | Heat treated 4130 CrMo / CNC / Offset thickness |
| Bottom Bracket | Heat treated 4130 CrMo / CNC machined |
| Chainstay Yoke | Heat treated 4130 CrMo / Invest cast |
| Dropouts | Heat treated 4130 CrMo / Invest cast |
| Seatclamp | Built in |
Finish: Matte
*BSD brake mount kit available separately.
