S&M ATF XL Frame
S&M ATF XL Frame
Normaler Preis
$515.99
Normaler Preis
Verkaufspreis
$515.99
Grundpreis
pro
Versand wird beim Checkout berechnet
Verfügbarkeit für Abholungen konnte nicht geladen werden
This is the frame that Aryei Levenson wanted & it does it all. The ATF XL takes the tried & true ATF frame to the next level. With a taller 5″ head tube, 9″ stand over & extended top tube sizes up to 22″, it’s built for the tall team. The perfect blend of responsiveness & stability, ready for action on all terrains. Aryei signed off on the “Purple Haze” colorway, too.
| TOP TUBE LENGTHS | 21″, 21.25″,21.5″,22″ |
| REAR END LENGTH | 13.4″ |
| HEAD TUBE ANGLE | 75° |
| HEAD TUBE STYLE | Integrated (45°/45°, 41.8mm) |
| SEAT TUBE ANGLE | 71° |
| SEAT CLAMP | Integrated |
| SEAT POST SIZE | 1″ (25.4mm) |
| BB HEIGHT | 11.7″ |
| BB STYLE | Mid |
| STANDOVER HEIGHT | 9″ |
| BRAKE MOUNTS | Thread-On 990 (Mounts sold separately) |
| DROPOUTS | 14mm Slot, 4Q-Baked |
| GYRO TABS | None |
| WEIGHT | 4.75 lb (2.15 kg) |
| TUBESET | Butted True Temp |
