BSD ALVX AF + Frame

The ALVX AF is the latest incarnation of the ALVX frame, this new version features a super tech invest cast chain stay yoke which gives even more tire clearance as well as stiffening up the rear triangle. Your wheel can be slammed at an extremely short 12.5" CS length w/ no worries of your tire rubbing!!

KEY FEATURES:

Alex Donnachie signature
Super short rear end slammable to 12.5"

SPECS:

Toptube lengths	20.3" / 20.6" / 20.8" / 21"
Headtube angle	75.5°
Headtube length	117mm
Seattube angle	71°
Rear end length	12.5-13"
BB Height	11.7"
Standover height	8.7"
Weight	5lbs
Brake mounts	none - brakeless
Tubing	Sanko Japanese seamless 4130 CrMo / triple butted
Headtube	Heat treated 4130 CrMo / CNC / Offset thickness
Bottom Bracket	Heat treated 4130 CrMo / CNC machined
Chainstay Yoke	Heat treated 4130 CrMo / Invest cast
Dropouts	Heat treated 4130 CrMo / Invest cast
Seatclamp	Built in
